VietMX Staff asked 3 years ago
The KMP algorithm is an efficient string matching algorithm due to Donald Knuth, Vaughan Pratt, and James H. Morris.
For the string matching problem (find p in S) the naive approach would be to slide a window of size p all over S and check if it matches. That works but actually is inefficient. It takes O(p*S) time.
Instead of naive approach KMP is a linear time (O(n)) algorithm that exploits the observation that every time a match (or a mismatch) happens, the pattern itself contains enough information to dictate where the new examination should begin from. Every time the naive function fails (or succeeds), it starts matching over from the next character. This might not be necessary. We could use our knowledge of the point of last matching and the “structure” of the test string to know where the next matching should begin from.
How To Understand Prefix Function and Partial Match Table?
The “structure” of the string is encapsulated in the Prefix (or Failure) Function that we use to create Partial Match Table. Now, in order to talk about the meaning, we need to know about proper prefixes and proper suffixes.
- Proper prefix: All the characters in a string, with one or more cut off the end. “S”, “Sn”, “Sna”, and “Snap” are all the proper prefixes of “Snape”.
- Proper suffix: All the characters in a string, with one or more cut off the beginning. “agrid”, “grid”, “rid”, “id”, and “d” are all proper suffixes of “Hagrid”.
Saying that here’s the partial match table for the pattern abababca where each cell value is “The length of the longest proper prefix in the (sub)pattern that matches a proper suffix in the same (sub)pattern”.
char: | a | b | a | b | a | b | c | a |
index: | 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 |
value: | 0 | 0 | 1 | 2 | 3 | 4 | 0 | 1 |Let’s also try it for cell five, which concerns “ababa”. We have four proper prefixes (“a”, “ab”, “aba”, and “abab”) and four proper suffixes (“a”, “ba”, “aba”, and “baba”). Now, we have two matches: “a” and “aba” are both proper prefixes and proper suffixes. Since “aba” is longer than “a”, it wins, and cell five gets value 3.
How To Use Partial Match Table?
We can use the values in the partial match table to skip ahead (rather than redoing unnecessary old comparisons) when we find partial matches. The formula works like this:
If a partial match of length partial_match_length is found and
table[partial_match_length] > 1, we may skip aheadpartial_match_length - table[partial_match_length - 1]characters.*
Let’s say we’re matching the pattern “abababca” against the text “bacbababaabcbab”. Here’s our partial match table again for easy reference:
char: | a | b | a | b | a | b | c | a |
index: | 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 |
value: | 0 | 0 | 1 | 2 | 3 | 4 | 0 | 1 |The first time we get a partial match is here:
bacbababaabcbab
|
abababcaThis is a partial_match_length of 1. The value at table[partial_match_length - 1] (or table[0]) is 0, so we don’t get to skip ahead any. The next partial match we get is here:
bacbababaabcbab
|||||
abababcaThis is a partial_match_length of 5. The value at table[partial_match_length - 1] (or table[4]) is 3. That means we get to skip ahead partial_match_length - table[partial_match_length - 1] (or 5 - table[4] or 5 - 3 or 2) characters:
// x denotes a skip
bacbababaabcbab
xx|||
abababcaThis is a partial_match_length of 3. The value at table[partial_match_length - 1] (or table[2]) is 1. That means we get to skip ahead partial_match_length - table[partial_match_length - 1] (or 3 - table[2] or 3 - 1 or 2) characters:
// x denotes a skip
bacbababaabcbab
xx|
abababcaAt this point, our pattern is longer than the remaining characters in the text, so we know there’s no match.
Things to remember:
- Once table is built, this algorithm has complexity
O(n)even for binary alphabet (compare withO(m*n)for brute force). - Table is built very quickly at start since pattern is usually very small.
- Table-building part is
O(m). Search part isO(n). Total complexityO(m+n)even on binary alphabet. - Compare with
O(m*n)for brute force on binary alphabet.
- Because the prefix-function already tells us what needs to be done about the already matched parts, we do not need to check those parts again and hence, only one pass over the string is sufficient. So, the time complexity of the matching is
O(n). - What about the pre-computation? It turns out that, if correctly implemented, it can be done in
O(m)time wheremis a length of a pattern. - Overall, it takes
O(m+ n)time. But sincem≤ n, the time is bounded byO(n). This is certainly better than the usualO(n2) - We only require as much space as the pattern. So, the space requirement is
O(m).
public static int KMP(String search, String target) {
int[] failureTable = failureTable(target);
int targetPointer = 0; // current char in target string
int searchPointer = 0; // current char in search string
while (searchPointer < search.length()) { // while there is more to search with, keep searching
if (search.charAt(searchPointer) == target.charAt(targetPointer)) { // case 1
// found current char in targetPointer in search string
targetPointer++;
if (targetPointer == target.length()) { // found all characters
int x = target.length() + 1;
return searchPointer - x; // return starting index of found target inside searched string
}
searchPointer++; // move forward if not found target string
} else if (targetPointer > 0) { // case 2
// use failureTable to use pointer pointed at nearest location of usable string prefix
targetPointer = failureTable[targetPointer];
} else { // case 3
// targetPointer is pointing at state 0, so restart search with current searchPointer index
searchPointer++;
}
}
return -1;
}
/**
* Returns an int[] that points to last valid string prefix, given target string
*/
public static int[] failureTable(String target) {
int[] table = new int[target.length() + 1];
// state 0 and 1 are guarenteed be the prior
table[0] = -1;
table[1] = 0;
// the pointers pointing at last failure and current satte
int left = 0;
int right = 2;
while (right < table.length) { // RIGHT NEVER MOVES RIGHT UNTIL ASSIGNED A VALID POINTER
if (target.charAt(right - 1) == target.charAt(left)) { // when both chars before left and right are equal, link both and move both forward
left++;
table[right] = left;
right++;
} else if (left > 0) { // if left isn't at the very beginning, then send left backward
// by following the already set pointer to where it is pointing to
left = table[left];
} else { // left has fallen all the way back to the beginning
table[right] = left;
right++;
}
}
return table;
}
